Japan HIOKI IR4057-50 insulation high resistance meter original company goods (FKH4057-50)
$12,800.00
Unit price perJapan HIOKI IR4057-50 insulation high resistance meter original company goods (FKH4057-50)
$12,800.00
Unit price perHIOKI insulation high resistance meter/high resistance meter adopts an integrated design.
IR4057-50 is an insulation high-resistance meter with 5 ranges and a test voltage of 50V/100MΩ~1000V/4000MΩ. It has powerful functions and fast response speed, which helps shorten on-site working time.
- Supports wireless communication: transmits measurement results to smartphones or tablet devices, and allows you to combine test results with on-site photos or drawings to quickly create reports (when used with wireless adapter Z3210), thus helping to shorten the time on site Insulation measurement working time
- Measurement data will be directly input into the Excel form through wireless transmission (this function is expected to be included in the 2021 version upgrade)
- 5 test ranges from 50 V / 100MΩ to 1000 V / 4000MΩ
- digital scale bar
- Stable and high-speed digital display, PASS/FAIL judgment response time is only 0.3 seconds
- Can withstand the impact of a 1m drop on concrete
- High-brightness LED display screen, test line with LED light switch (option L9788-11 or L9788-10)
- 200mA test continuous check, can measure AC/DC voltage
- Suitable for testing solar power systems and electric vehicles
IR4057-50 insulation resistance meter, supports wireless communication
When used with the wireless adapter Z3210 (Z3210 is an optional accessory and needs to be purchased separately), the measurement results can be transmitted to a smartphone or tablet device, and allows you to combine the test results with on-site photos or drawings to quickly create reports .
For a detailed introduction to Z3210, please click here .
Product specifications:
| Test voltage | 50VDC | 125VDC | 250V DC | 500VDC | 1000V DC |
| Effective maximum display value | 100 MΩ | 250 MΩ | 500 MΩ | 2000 MΩ | 4000 MΩ |
|
Accuracy 1st effective measurement range MΩ |
±4% rdg. 0.200-10.00 |
±4% rdg. 0.200-25.0 |
±4% rdg. 0.200-50.0 |
±4% rdg. 0.200-500 |
±4% rdg. 0.200-1000 |
| Minimum measured resistance value | 0.05 MΩ | 0.125 MΩ | 0.25 MΩ | 0.5 MΩ | 1 MΩ |
| Overvoltage protection |
AC 600V (10s) |
AC 660V (10s) | |||
| DC voltage |
4.2V (resolution 0.001V)~600V (resolution 1V), 4 ranges,
Accuracy: ±1.3% rdg. ±4 dgt., Input resistance: 100 kΩ or more
|
||||
| AC voltage |
420V (resolution 0.1V) / 600V (resolution 1V), 2 ranges, 50/60 Hz,
Accuracy: ±2.3% rdg. ±8 dgt., Input resistance: 100 kΩ or more, average value
|
||||
| low resistance | Used to check the continuity of the ground wire, 10 Ω (resolution 0.01 Ω)~1000 Ω (resolution 1 Ω), 3 ranges, basic accuracy: ±3 % rdg. ±2 dgt., test current 200 mA or more ( When 6Ω or less) | ||||
| show | FSTN LCD with backlight, digital scale bar | ||||
| response time | PASS/FAIL judgment takes about 0.3s (under the conditions specified by HIOKI) | ||||
| Other functions | Display MΩ measurement value after 1 minute, live circuit alarm, automatic discharge, automatic DC/AC check, comparator, anti-fall, automatic power saving | ||||
| power supply |
No. 3 (LR6) alkaline batteries x 4, continuous use: 20 hours (based on internal testing)
Number of measurements: 1000 times (5sON, 25sOFF loop, insulation measurement from the lowest measured resistance value to maintaining rated measurement voltage)
|
||||
| Volume and weight | 159 mm W × 177 mm H × 53 mmD, 640 g (including battery and test leads) | ||||
| appendix | Connecting cable L4930 × 1, alligator clip L4935 × 1, test pin L4938 × 1, lanyard × 1, instruction manual × 1, size 3 (LR6) alkaline batteries × 4 | ||||
- Non-contact voltage test pen made in Taiwan (test pen, test screwdriver, test screwdriver, test pen)
- Excellent AC voltage detector made in Taiwan
- When using a test pen, you can measure the presence of voltage without contact.
- The electrical test screwdriver can measure wires, cables, sockets, fuse switches, control inventory repairs, etc.
- It can directly test whether the AC voltage is energized or leaked. It has LED lights and beeping sounds to ensure safe use.
- When inspecting circuits during engineering maintenance, there is no need to cut open the wires to avoid the risk of electric shock.
- The pen-type design of the electric test screwdriver is easy to carry
- Suitable for household AC voltage detection, not for DC
Product specifications:
- Uses LR44 1.5V batteries x2 (included)
- AC voltage test: AC70V ~440V
- Material: ABS
Origin:
Taiwan
- Four-stage voltage detectors made in Taiwan (four-stage voltage and current detectors, four-stage AC and DC voltage detectors, four-stage voltage testers, four-stage voltage detectors, four-stage electroscopes)
- The four-stage voltage detector can determine the voltage in the AC/DC circuit and is a common and convenient tool for checking whether low-voltage electrical equipment is leaking.
- Four-stage voltage detection instrument, each stage uses independent resistors, suitable for various regions
- When detecting AC alternating current, the neon tubes at the two electrode ends will light up.
- When detecting DC current, only one electrode of the neon tube will light up.
- When testing, one end needs to be connected to the live wire (positive pole) of the power socket, and the other end needs to be connected to the ground wire (negative pole), then the neon tube will light up.
- No batteries required
- The voltage tester is suitable for AC alternating current testing and DC direct current, and is suitable for home use.
- Voltage measurement range: 110V~460V
- Palm size, lightweight, easy to carry, the best tool for DIY and professional instruction
- Suitable for testing power sockets, switches, short circuit detection, fuses, two electrodes, main power supplies, and other equipment
Product specifications:
- Voltage range: 110V-220V-277V-460V AC/DC
- Material: ABS fireproof material
- Total length: 10.9cm
Instructions for use:
- Please place the red/black ends of the four-segment voltage detector at the two ends of the power socket or other measuring object to measure its voltage.
- When detecting AC voltage value, this product will display a double row of neon lights on the voltage display value, and DC will display a single row of neon lights.
Precautions:
- When measuring the voltage value, you should first make sure that the voltage value of the power supply is less than 460V to avoid danger.
- The four-stage voltage detector is an auxiliary simple detection product. Detailed data should be based on an electric meter or precision measuring instrument.
- When using the four-stage voltage detector, please keep your hands and electroscope dry to avoid danger.
- AC and DC voltage detectors (voltage and current detectors, voltage testers, voltage detectors, electroscopes) made in Taiwan
- The voltage detector can determine the voltage condition in the AC/DC circuit; it is a common and convenient tool to check whether low-voltage electrical equipment is leaking.
- High brightness display, easy to identify
- Double circuit reinforced insulation protection
- Compact and easy-to-carry electroscope
- US ETL certification
Product specifications:
- Voltage range: 100-250V (AC/DC), frequency 50-60Hz
- Current consumption:
- Material: Body ABS+TPR covering
Environmental conditions:
- Operating environment temperature: -5℃~40℃
- The floating voltage must not exceed 10% of the standard voltage
- This instrument refers to the insulation class (overvoltage category II)
- Pollution level two
Precautions:
- The maximum measuring voltage value of the AC and DC voltage detector is 300V, and the voltage indication range is 80-300V AC/DC. It cannot be considered that the neon lamp does not light up, which means that the object under test is not charged.
The Fluke 301E AC/DC blade series hook meter has a thin and compact body that can be carried in your pocket. The thin-pointed jaw design can easily clamp densely packed cables. Fluke 301E also integrates multiple functions of current, voltage, resistance, continuity, frequency (voltage frequency and current frequency), capacitance, and diode. You can handle more testing needs with one clamp meter.
The AC and DC current test functions can be applied to more new energy photovoltaic and wind power, new energy vehicles, communications, data centers and other application scenarios that require DC testing.
feature of product:
- The body weighs only 154g and is 16mm thick. It is thin, light and portable and can be put in your pocket.
- 10mm fine-tip pliers, easily clamp into densely packed cables
- AC and DC 1000A range, 0.01A high resolution
- Voltage, resistance, continuity test function
- Current frequency, voltage frequency test function
- Capacitor and diode test function
- Backlight function
Fluke 87V digital multimeter multimeter original company product (BI-FK-87V)
Fluke 87V digital multimeter multimeter original company product (BI-FK-87V)
Fluke 87V has greatly improved measurement functions, diagnostic functions, resolution and accuracy, and can solve more problems in motor drives, factory automation equipment, power distribution and electromechanical equipment. Fully meets the requirements of ANSI/ISA S82.01 second edition and EN61010-1 CAT IV 600V/CAT III 1000V standards. Can withstand voltage pulses above 8,000 V, greatly reducing the risk of surges and breakdowns.
Protection classes for all inputs are Category III, 1000 V and Category IV 600 V. Can withstand pulses above 8,000 V, greatly reducing the risk of surges and breakdowns.
Proper measurement of pulse width modulated motor drive signals
Fluke 87V is designed specifically for the complex signals generated by speed-regulated motor drives. Potential productivity will be gained by eliminating the need to guess at drive system failures. Every measurement and every measurement is precise.
feature of product:
- Accurately measure noisy pulse-width modulated AC voltages. Measurements can be made on the ASD and motor terminals.
- Accurately measures frequency (motor speed). Frequency measurement is not affected by ASD load frequency
- Using the optional current clamp accessory, AC current can be measured
- Compare the 87V reading to the value displayed on the ASD
- Special masking measures prevent the impact of high-frequency and high-energy noise generated by large drive systems
Fluke 15B+ digital multimeter, professional-grade accuracy, durability and safety. The Fluke 15B+ combines all the core features you need in a digital multimeter into a portable, durable tool that can be easily operated with one hand, even when wearing gloves. From AC/DC voltage and current measurements (up to 1000V and 10A) to comprehensive functionality including resistance, capacitance and frequency checks, the 15B+ is the tool of choice for troubleshooting a wide range of electrical problems.
The CAT III 600V safety rating gives you peace of mind when performing routine inspections of electrical equipment and appliances, measuring voltage levels at electrical outlets or switches, or diagnosing circuit problems. The Fluke 15B+ is not only suitable for DIY enthusiasts, but also for novice electricians who want to simplify their toolbox. It is a reliable and versatile addition to your toolbox.
Product Features:
- 600 V CAT III safety rating
- AC/DC voltage measurement up to 1000V
- AC/DC current measurement up to 10A
- Measure voltage, resistance, continuity, capacitance
- Diode test, data hold
- Large, easy-to-read display with white backlight
Specifications:
| Function | Range | Resolution | Accuracy |
| AC DC Volts (40 Hz to 500Hz) | 4.000 V 40.00 V 400.0 V 1000 V |
0.001 V 0.01 V 0.1 V 1 V |
1.0% + 3 |
| DC Direct Current Volts | 4.000 V 40.00 V 400.0 V 1000 V |
0.001 V 0.01 V 0.1 V 1 V |
0.5% + 3 |
| AC alternating current millivolts | 400.0 mV | 0.1 mV | 3.0% + 3 |
| DC direct current millivolts | 400.0 mV | 0.1 mV | 1.0% + 10 |
| Resistance (Ohm) | 400.0 Ω 4.000 kΩ 40.00 kΩ 400.0 kΩ 4.000 MΩ 40.00 MΩ |
0.1 Ω 0.001 kΩ 0.01 kΩ 0.1 kΩ 0.001 MΩ 0.01 MΩ |
0.5% + 3 0.5% + 2 0.5% + 2 0.5% + 2 0.5% + 2 1.5% + 3 |
| capacitance | 40.00 nF 400.0 nF 4.000 μF 40.00 μF 400.0 μF 1000 μF |
0.01 nF 0.1 nF 0.001 μF 0.01 μF 0.1 μF 1 μF |
2% + 5 2% + 5 5% + 5 5% + 5 5% + 5 5% + 5 |
| Maximum voltage between any terminal and ground | 1000V | ||
| Operating temperature | 0 °C to 40 °C | ||
| Storage temperature | -30 °C to 60 °C | ||
| Dimensions (H x W x L) | 183 x 91 x 49.5 mm | ||
| weight | 455 g | ||
Origin: China
- Taiwan-made motorcycle battery analyzer (battery tester, battery analyzer, battery life analyzer, battery tester)
- Accurately analyze 4 indicators of the battery: voltage, CCA value, resistance, and battery life status
- Simple, fast, accurate and safe testing to easily estimate battery life
- Estimate your battery life and drive safer
- Safety: Conductivity testing, continuous testing without danger, will not harm the battery
- Simple: find out the battery model, enter the data and start testing
- Accurate: Unique internal resistance and lifespan display makes judgment more accurate
Product specifications:
- Working voltage: 9-15V
- Working current: dedicated to locomotives
- Measuring battery: 100-700 CCA
- Measurement standards: 4, 5, 7, 9, 10, 12
- Working temperature: -20 ~ 50℃
綠光4D 16線雷射水平儀
取代傳統墨線,採用高亮度綠光雷射與智慧型自動調平技術,大幅提升工作效率,是安裝施工的理想利器,適用於磁磚鋪設、木作裝潢、電工佈線、門窗安裝等多種場景。
產品特色:
• 4D 16線高精準標線:水平/垂直全覆蓋,定位快速精準
• 綠光雷射:亮度高、射程遠,室內外均清晰可見
• 智慧自動調平:≤3°自動調整,超出範圍持續閃爍並嗶嗶聲提醒
• 多種安裝方式:支援腳架、升降台、牆貼等
• 一鍵鎖定斜線模式:支援斜面施工需求
• 亮度調節+遠端遙控:依環境調整光線,操作更便利
• 清晰4鍵介面:水平、垂直、斜線、亮度獨立控制,直覺易用
• 堅固便攜:附收納盒,攜帶安裝兩相宜
• 適用多種工程場域:地磚鋪設、室內裝修、電力/木工安裝等
警告:使用時,雷射光請勿直接對準眼睛或從反射面間接照射,否則可能會對眼睛造成永久傷害
Capable of entering tight spaces with a multi-directional articulating head, this borescope is ideal for precise inspections and maintenance tasks. Whether you're working in pipelines, HVAC systems, automotive repairs, mechanical maintenance, or home inspections, the short-lens articulating endoscope meets your needs. The dual-direction articulating camera allows fast and accurate diagnostics, improving your work efficiency.
The short-lens articulating endoscope features 160° dual-direction articulation and a 360° rotatable snake tube, allowing for thorough, dead-angle-free inspections. With a 7-inch HD screen and 1MP resolution, it delivers crystal-clear images. Its IP67 waterproof rating and 5-level adjustable LED brightness make it easy to navigate through narrow or curved gaps and locate hard-to-see areas.
Product Features:
■ 720P HD resolution: Clear image detail for improved inspection accuracy.
■ 360° flexible control: Fully rotatable camera head for versatile, in-depth inspections.
■ 7-inch IPS widescreen: Sharp and distortion-free display, supports HDMI output.
■ Durable insertion tube: Outer braided abrasion-resistant material for long-lasting use.
■ 5-level adjustable LED light: Adapt brightness freely to suit various environments.
■ IP67 water and dust resistance: Industrial-grade protection for both camera and cable.
■ Photo and video support: Comes with a 16GB memory card for instant media capture and storage.
■ Long-lasting battery: Up to 8 hours of continuous use on a single charge.
■ Multilingual interface: Supports multiple languages including English and Chinese for easy operation.
